Description
| Product Name | PCB Mount Current-type Voltage/Potential Transformer PT |
| P/N | MLVC-2144 |
| Installation method | PCB mounted |
| Rated input current | 2mA/2mA |
| Hi-pot test | 3000V-4000V/1mA1min |
| DC resistance | DC500V/100M ohm |
| Core Material | Ultra crystalline Core |
| Accuracy | 0.1,0.2,0.5 |
| Load Resistance | 20Ω,50Ω,100Ω |
| Insulation resistance | ≥500MΩ (500VDC) |
| Insulation withstand voltage | 4KV/1mA/60S |
| Operating Frequency | 50-400Hz |
| Operating Temperature | -25℃ ~ +75℃ or -40℃ ~ +95℃ |
| Insulation | Epoxy resin encapsulated |
| Outer Case | Flame Retardant PBT |
| Application | Voltage isolation measurement, power compensation, microcomputer protection, current measurement, precision power meter, Instrument and sensors |
Features
Small in size
Various of configuration and output characteristics, customized products are welcome
High precision
Nanocrystalline core
Very high linearity
PCB mounted, epoxy resin encapsulated
Excellent linearity over the whole range
| Rated input and output | Current ratio | Accuracy class | Load resistance | Frequency |
| 2mA/2mA | 1000:1000 | 0.1 or 0.2 | ≤150 | 50-400Hz |
| 2mA/2mA | 1000:1000 | 0.1 or 0.2 | ≤150 | 50-400Hz |
| 1mA/1mA, 2mA/2mA | 1000:1000 | 0.1 or 0.2 | ≤500 | 50-400Hz |
| 2mA/2mA | 1000:1000 | 0.1 or 0.2 | ≤200 | 50-400Hz |
